Support 1 way H.264 video stream and 1 way MJPEG video stream simultaneously. Adopt mega pixels CMOS sensor, support 720p video resolution
1) Sensors: 1/4 CMOS sensor
2) The minimum illumination: 0.5LUX@550nm
3) Lens type: glass lens, 6mm
4) Audio: support two way audio monitoring
5) Ethernet: one 10/100Mbps RJ-45
6) Support protocol: HTTP, FTP , TCP / IP, UDP, SMTP, DHCP, PPPoE, DDNS, UPnP
7) Wireless standard: IEEE 802.11b/g/n, WPS, WPS automatically configures the network name (SSID) and WPA security key for the access poin
8) Infrared light: 10 IR LEDs, night visibility up to 10 metres
9) Alarm input: 1 channel on/off input
10) Alarm output: 1 channel 5V relay output
11) Power supply: DC 5V/2A
12) Power consumption: 5 watts
|
Model |
MF-HK3 |
|
Sensor |
million pixels low illumination CMOS image sensor |
|
Size |
1 / 4 CMOS sensor |
|
Effective Pixels |
Million pixels:1280*720 |
|
Minimum illumination |
0.5LUX@550nm |
|
Infrared sensitivity |
Yes |
|
Filter |
Yes |
|
Camera lens |
10 IR LEDs, night visibility up to 10 metres |
|
Visual angle |
horizontally 270°,vertically 120° |
|
Infrared distance |
10m |
|
Motion detection |
Yes |
|
Electronic shutter |
Support WIFI |
|
Backlight compensation |
1/5-1/15,000 sec |
|
Aperture |
Yes |
|
White balance |
Auto |
|
S/N Ratio |
Auto |
|
Video compression Format |
>50 dB |
|
Picture sharpness |
H.264 |
|
Bit rate |
million pixels : 1280*720 |
|
Image frequency |
80 K~ 2.0 M bps |
|
Audio |
support two way audio monitoring |
|
Alarm input |
1 channel on/off input |
|
Alarm output |
1 channel 5V relay output |
|
Ethernet |
one 10 / 100Mbps RJ-45 |
|
Protocol |
Ethernet (10/100 Base-T),RJ-45 connector |
|
Web Browser |
HTTP, FTP , TCP / IP, UDP, SMTP, DHCP, PPPoE, DDNS, UPnP |
|
Wireless standard |
IEEE 802.11b/g/n, WPS, WPS automatically configures the network name (SSID) and WPA security key for the access |
|
Size |
10 x 10 x12cm |
|
Weight: |
303g |
|
Humidity |
-30°~60°C |
|
Power requirement |
-10~85% |
|
|
DC 5V2A | |
