Item NO.

MF-NIRD7BD

MF-NIRD7BZ

MF-NIRD7BG

Network Chip

Realtek 10/100M

Realtek 10/100M

Realtek 10/100M

Image Sensor

1/4" CMOS 1.3 Megapixel sensor

1/3" CMOS 1.3 Megapixel AR0130

1/2.5" CMOS 2.0 Megapixel

Effective Pixels

1280(V)*720(H)

1280(V)*960(H)

1920(V)*1080(H)

Min. Illumination

color 0.1lux/F1.2, B/W 0.01lux/F1.2

Video coding

H.264 Main Profile coding

Main Stream

1280(V)*720(H),1-30fps

1280(V)*960(H),1-30fps

1920(V)*1080(H),1-30fps

Sub Stream

D1, 1~30fps

Video Compressed

0.1Mbps～4Mbps,CBR/VBR supported

Subtitles Superimposed

Chanel Name, Date And Time Supported

Video Code

G.711,G726 32K Stereo Supported

Lens

3.6/6mm 3.0 Megapixel Lens

IR Range

30m

I/O input and output

1CH for switching value input/1CH for switching value output

Network Interface

10/100M Ethernet Port,RJ45

Data Storage

Video, Image Files

Storage Mechanisms

Manual, Auto(Cycling, Timing, Alarm switch, Motion detecting)

Alarm Data Transmission

Browser, Software management

Protocols

TCP/IP,UDP,RTP,RTSP,RTCP,HTTP,DNS,DDNS,DHCP,PPPOE,UPNP

ONVIF Protocols

Standard ONVIF2.0

Personal Computer

IE, Firefox, Safari etc.

Smart phone

Smart phone and iphone Platform

Operating Temperature

-20℃~+60℃

Operating humidity

0% ~90%

Power Supply

DC12V

Power Consumption

5W

Dimension

Ø125 x 117(H) mm

Weight

500g
