PWM function, intelligent IR illumination & power consumption is variable, dependant the zoom factor
◆ IR distance 150M, Multiple languages for OSD menu, English, Spanish etc.
◆ Support ambient light detection, IR Illumination On 1-15 grade selectable
◆ Dome ID, baud rate, communication protocol can be set via the controller
◆ Supported Protocols: Onvif2.0
◆ 7" Double layer metal body construction, waterproof IP 66
◆ Optional 1.3 Megapixel/2.0 Megapixel module
◆ Optional, 4 Alarm inputs and 2 alarm outputs
|
Model No. |
MF-NPTZ1ZC18X |
MF-NPTZ1GC20X |
MF-NPTZ1GK20X |
MF-NPTZ1GJ20X |
|
Image Sensor |
18X Optical Zoom |
20X Optical Zoom |
|
Resolution |
1/3" CMOS 1.3 Megapixel AR0130 |
1/2.5" CMOS 2.0 Megapixel |
|
Electronic Shutter |
NTSC:1/60-1/100,000 second< PAL:1/50-1/100,000 Second |
|
Gamma |
0.45/1(Set To 0.45 Before shipment) |
|
Lens |
18X /20X |
|
Video Output |
1.0Vp-p,75Ω,Composite |
|
AGC |
AUTO |
|
BLC |
AUTO |
|
AWB |
AUTO |
|
Scanning system |
2:1 Internal |
|
S/N Ratio |
＞52dB |
|
Sync system |
Internal |
|
IR Leds |
11PCS |
|
IR Distance |
150m |
|
Power Supply |
＜500mA (IR) DC12V |
|
Life time |
20,000 hours |
|
Temperature |
-30℃ ~ +60℃ |
|
Dimension |
Ø210x380mm |
|
Weight |
8.5Kg |
|
Power |
12VDC |
