Key Features:
◆ Can connect IP camera, IP speed dome camera and DVS; support Onvif protocol;
◆ Compatible with main brand IP cameras: AXIS, SONY, Panasonic, SANYO, BOSCH, SAMSUNG, Honeywell, VIVOTEK, Ambarella, HIKVISION, DAHUA, Histream, Grandstream, TOPSEE, Launch, WISION, HYVISION, WAPA etc.;
◆ Support megapixel HD network video preview, storage and playback;
◆ Click any area and zoom in or zoom out on the image by mouse;
◆ Support digital zooming under preview and playback modes;
◆ Support search, playback and backup by event;
◆ Support 4ch playback simultaneously
Parameter:
|
Model Number |
MF-MNVR04 |
|
Operating System |
Embedded LINUX operating system |
|
Image Code Control |
Image code quality adjustable, variable bitstream and
constant bitstream optional |
|
Dual Stream |
Each channel can set main stream and sub stream |
|
Video Standard |
1080P(1920×1080)30fps/960P/(1280×960)/720P
(1280×720)30fps |
|
Monitoring Image
Quality |
1080P(1920×1080) / 960P/(1280×960)/720P
(1280×720) |
|
Image Motion Detection |
Each screen can set mutiple detection areas and set 6-
level sensitivity（IPC Support） |
|
Recording Playback
Quality |
4ch playback in 4ch 720/960P mode;1ch 1080P playback
in 1/4ch 1080P mode |
|
Region Cover |
Every channel can set 4 cover regions（IPC Support） |
|
Recording Mode |
Support manual , auto, dynamic detection, alarm trigger
record mode(Partly needs IPC Support) |
|
Backup Way |
Support U disk, USB mobile HDD, USB DVD-RW, network
storage and backup |
|
Operation Way |
Mouse |
|
Local Login |
User name and password |
|
Recording Storage |
Local HDD, network |
|
External
Ports |
Video Input |
①4×(1280*720)+sub[960*576]+4Ref.+4Play Support
4ch 1MP IP camera |
|
②4×(1280*960)+sub[960*576]+1Ref.+4Play Support
4ch 1.3MP IP camera |
|
③4×(1920*1080)+sub[960*576]+4Ref.+1Play Support
4ch 2MP IP camera |
|
④1×(1920*1080)+sub[960*576]+4Ref.+1Play Support
1ch 2MP IP camera |
|
⑤4×(720*576)+sub[352*288]+4Ref.+4Play Support
4ch 0.4MP IP camera |
|
Audio Input |
4ch network audio input |
|
Video Output |
1ch VGA+1ch HDMI |
|
Network Port |
1 RJ45,10M/100M self-adaptive LAN port |
|
USB Port |
2 USB 2.0 ports |
|
Wireless Port |
3G，WIFI |
|
HDD |
Mobile HDD/E-SATA/USB Disk |
|
Mobile Surveillance |
Support( iPhone, Windows Mobile, BlackBerry, Symbian,
Android) smart phone |
