Model No.

MF-SA30X

Image Sensor

1/4'' sony  Interline Transfer CCD

Effective Pixels

PAL: 752 (H) x 582 (V)

NTSC: 768 (H) x 494 (V)

Sensing Area

3.6mmx2.4mm

Singal Syetem

PAL/NTSC

Horizontal Resolution

600TVL

Bulid-in Lens

30X, 3.5mm-94.5 mm

Minimum Illumination

0.01LUX

Sync. System

Internal

Shutter Speed

1/50(1/60)-1/100,000 (S)

S/N Ratio

≥52dB (AGC Off)

OSD

English/Chinese

White Balance

Auto

Color To White

Auto

Control Interface

Wire, RS485

Video Output

1.0Vp-p75Ω

Power Reqiurement

DC12V, 750mA, 3.6W

Video Out

BNC

Weight

0.4KGS

Size:

126mm*72mm*63mm
