Tri-Color Display (Black/White/Red): Enhances visual impact, ideal for price changes, promotional alerts, or attention-grabbing labels.
Ultra-Low Power Consumption: Power is only consumed during content refresh, enabling multi-year battery life.
Excellent Readability: Reflective display provides high contrast and paper-like readability, even in strong ambient light or sunlight.
Wide Viewing Angle: Up to 180°, ensuring easy reading from different positions.
Wireless Update Capability: Supports RF, BLE, or NFC for centralized management and real-time updates via gateway systems.
Retail: Medium-sized shelf labels, promotional signage, product information
Supermarkets: Real-time pricing and stock display
Warehousing & Logistics: Bin and rack labels, status indicators
Smart Offices: Room signs, employee badges, or resource booking displays
Product Dimensions (mm) | 85.79 x 41.89 x 12.3 |
Case Color | Black, White |
Display Color | Black/White/Red |
Display Area (mm) | 60.09 x 30.70 |
Display Resolution (Pixel) | 296 x 152 |
DPI | 125 |
NFC | Support (Optional) |
Multiple Pages | Support 8 pages |
LED | Red, Green, Blue, three primary colors, Support 7 colors |
Operating Temperature | 0°- 40°C |
Ambient Humidity | 45% - 70%RH |
Battery Type | Button Battery |
Battery Life | >10 years |
Waterproofing Level | IP54 |
Certification | CE, RoHS, FCC, MIC |
Communication Frequency Band | 2.400-2.480 GHz, Maximum EIRP ≤ 10mW |
